DIN43650A, DIN43650B, DIN43650C
Langch
The DIN 43650 coil connector is a standardized electrical connector commonly used in solenoid valves, pressure switches, and sensors in hydraulic and pneumatic systems. The DIN 43650 standard, also known as ISO 4400 or EN 175301-803, defines the specifications for the connectors, including their dimensions, pin configuration, and mounting requirements.
Here are the key points about the DIN 43650 coil connector:
1. Types and Configurations: There are several types of DIN 43650 connectors, identified as Form A, Form B, and Form C. Each form has different dimensions and pin configurations:
• Form A: The largest, typically used for solenoid valves and larger sensors.
• Form B: Smaller than Form A, used in more compact applications.
• Form C: The smallest, often used for miniature valves and sensors.
2. Pin Layout: DIN 43650 connectors typically have three pins (two for power and one for grounding), but variants with two pins are also available.
3. Construction: These connectors are made from durable materials such as plastic or metal to withstand harsh industrial environments. They often come with screw or snap-on caps to ensure secure and reliable connections.
4. Sealing: Many DIN 43650 connectors are designed with sealing gaskets to provide ingress protection against dust and moisture, often rated up to IP65 or higher.
5. Applications: They are widely used in industrial automation, especially in fluid control systems, including hydraulics and pneumatics, where reliable and robust connections are necessary.
Using DIN 43650 connectors ensures compatibility and interchangeability between components from different manufacturers, facilitating maintenance and reducing downtime in industrial settings.
